Special Band CPE
We are pleased to provide CPE products for the emerging and special markets. Our current special band CPE product line features ODU models for 3.3GHz LTE, 5GHz LTE and 5.1GHz AeroMACS (WiMAX). For customer with new special frequency band requirement, we will be happy to discuss the opportunity with you.
| Description | 3.3-3.4GHz High Performance LTE Outdoor CPE | ||
| Standards | 3GPP Release 9, Category 4 | ||
| Radio Operation | 1T2R, TxD, DL 2x2 MIMO, Optional UL QAM64 Support | ||
| B55 (3.3-3.4GHz) | 27dBm Tx | 17 dBi | |
| User Interface | 1 FE (PoE, 48V) | ||
| Dimension & Weight | 250mm(L) * 250mm(W) * 75mm(D) | 2.5kg | |
| Power Supply | 48V PoE Adapter | ||
| Description | Cost Effective LTE-U 5GHz Outdoor CPE | ||
| Standards | 3GPP Release 9, Category 4 | ||
| Radio Operation | 1T2R, TxD, DL 2x2 MIMO | ||
| Bands | Tx Power | Antenna gain | 5150 - 5250 MHz | 21dBm Tx | 15 dBi |
| 5825 - 5925 MHz | 21dBm Tx | 15 dBi | |
| User Interface | 1 FE (PoE, 24V) | ||
| Dimension & Weight | 310mm(L) * 122mm(W) * 75mm(D) | 1.5kg | |
| Power Supply | 48V PoE Adapter | ||
| Description | 5.1GHz AeroMACS(WiMAX)Outdoor CPE | ||
| Standards | AeroMACS & WiMAX 802.16e | ||
| Radio Operation | 1T2R, DL 2x2 MIMO, QAM64 Support | ||
| 5091 - 5150 MHz | 21dBm Tx | N-type Antenna Connector | |
| User Interface | 1 FE + 1 LINE (optional) | ||
| Dimension & Weight | 239mm(H) * 151mm(W) * 54mm(D) | 2.5kg | |
| Power Supply | 24V PoE Adapter | ||
