Physical & Environmental

Power

DC 48V/0.32A PoE Adapter, <15W

Weight

<1.5Kg

Dimensions

310mm(L) * 122mm(W) * 75mm(D)

Environment

Operating Temperature, -40℃~55℃. Humidity, 95% max Non-condensing

Water Resistance

IP67

LTE Radio Interface

Radio Access

3GPP LTE Release 9, Category 4

Operation Mode

TDD, 2RX, 1TxD, DL MIMO,

Frequency Band

5.150-5.250 GHz, 5.825-5.925 GHz

QoS Support

Non-GBR and GBR

Max Tx Power

21dBm

Antenna Gain

15dBi

User Interface

Data Interface

1 RJ45 10/100/1000M ETH Ports

LED Indicator

SYS, SIM, RF (4 Signal intensity LEDs)

SIM Card

Single USIM Card Slot (2FF)

Configurations & Management

LTE Networking

Multiple PDN interface support, IPv4 & IPv6 Networking Support, APN, Channel and Band Configuration, Network Selection and Cell Locking Provision, SIM Card Locking Feature.

Basic Data Networking

Router and L3 Bridge Operation Mode Support, Built-in DHCP Server for LAN Devices, VPN Pass-through support (PPTP, L2TP and IPSEC), Firewall & Access Control, DMZ and Virtual Server Support, IP and Port Filtering Support, NTP Service Support.

Advanced Networking Features

Built-in L2TP L2/L3 Tunneling client support, Built-in GRE L2/L3 Tunneling client support, Device Management Access Control, Application Firewall Support, LAN Device Access Control.

Device Management

CLI, Secure Telnet and WEB Management Interfaces, Standard TR-069 Management, OTA Upgrade Support (http, ftp, and TR069), Dual Image Bank Support for Safe Upgrade, Device Factory Default Setting.
