AirMaster 6300D


Physical & Environmental

Power

DC 48V/0.5A (Gigabit PoE), <20W

Weight

<2.5Kg

Dimensions

250mm(L) * 250mm(W) * 75mm(D)

Environment

Operating Temperature, -40~55. Humidity, 95% max Non-condensing

Water Resistance

IP67

LTE Radio Interface

Radio Access

3GPP LTE Release 10, Category 7

Operation Mode

2T4R or 2T2R, DL 4x4 MIMO, UL CA & MIMO, UL QAM64 Optional

Frequency Band

B38/40/41, B42/43/48

Channel Bandwidth

5/10/20/20+10/20+20MHz

QoS Support

Non-GBR and GBR

Max Tx Power

23dBm

Antenna Gain

B38/40/41: 10dBi

B42/43/48: 2T4R 14dBi,2T2R 17dBi

User Interface

Data Interface

1 RJ45 10/100/1000M ETH Ports

LED Indicator

PWR, SYS, LAN, SIM, RF (5 Signal intensity LEDs)

SIM Card

Single USIM Card Slot (2FF)

Configurations & Management

LTE Networking

Multiple PDN interface support, IPv4 & IPv6 Networking Support, APN, Channel and Band Configuration, Network Selection and Cell Locking Provision, SIM Card Locking Feature.

Basic Data Networking

Router and L3 Bridge Operation Mode Support, Built-in DHCP Server for LAN Devices, VPN Pass-through support (PPTP, L2TP and IPSEC), Firewall & Access Control, DMZ and Virtual Server Support, IP and Port Filtering Support, NTP Service Support.

Advanced Networking Features

Built-in L2TP L2/L3 Tunneling client support, Built-in GRE L2/L3 Tunneling client support, Device Management Access Control, Application Firewall Support, LAN Device Access Control.

Device Management

CLI, Secure Telnet and WEB Management Interfaces, Standard TR-069 Management, OTA Upgrade Support (http, ftp, and TR069), Dual Image Bank Support for Safe Upgrade, Device Factory Default Setting.





Preview picture




Feature Highlights

  • Cost effective & compact design with built-in high gain LTE & Wi-Fi MIMO antennas
  • Compliant to 3GPP LTE R10 specifications
  • Advanced 4x4 MIMO and CA support with Category 7 throughput
  • Router, bridge and by-pass networking, IPv4 & IPv6 and Multiple PDN support
  • USIM card authentication support
  • Secure Telnet, FTP, HTTP and TR069 OTA management support
  • Router, bridge and by-pass networking, IPv4 &v6 and Multiple PDN support
  • FTP, HTTP, HTTPS and TR-069 management support
  • Pole or wall mounting support
