Physical & Environmental

Power

DC 48V/0.5A (Gigabit PoE), <20W

Weight

<2.5Kg

Dimensions

250mm(L) * 250mm(W) * 75mm(D)

Environment

Operating Temperature, -40℃~55℃. Humidity, 95% max Non-condensing

Water Resistance

IP67

LTE Radio Interface

Radio Access

3GPP LTE Release 10, Category 6 & 7

Operation Mode

2T2R, DL 2x2 MIMO & CA, Optional UL QAM64 Support

Frequency Band

B38/40/41, B42/43

Channel Bandwidth

5/10/20/20+10/20+20MHz

QoS Support

Non-GBR and GBR

Max Tx Power

23dBm

Antenna Gain

B38/40/43: 14dBi

B42/43: 17dBi

Wi-Fi Interface (Optional)

2.4GHz

IEEE 802.11 b/g/n 300Mbps

5GHz

IEEE 802.11a/ac 867Mbps

Max Tx Power

15dBm

Antenna Gain

6dBi

User Interface

Data Interface

1 RJ45 10/100/1000M ETH Ports

1 RJ45 10/100M Outbound 12V PoE ETH Ports (Optional)

LED Indicator

PWR, SYS, LAN, SIM, 2.4GHz Wi-Fi, 5GHz Wi-Fi

RF (4 Signal intensity LEDs)

SIM Card

Single USIM Card Slot (2FF)

Configurations & Management

LTE Networking

Multiple PDN interface support, IPv4 & IPv6 Networking Support, APN, Channel and Band Configuration, Network Selection and Cell Locking Provision, SIM Card Locking Feature.

Basic Data Networking

Router and L3 Bridge Operation Mode Support, Built-in DHCP Server for LAN Devices, VPN Pass-through support (PPTP, L2TP and IPSEC), Firewall & Access Control, DMZ and Virtual Server Support, IP and Port Filtering Support, NTP Service Support.

Advanced Networking Features

Built-in L2TP L2/L3 Tunneling client support, Built-in GRE L2/L3 Tunneling client support, Device Management Access Control, Application Firewall Support, LAN Device Access Control.

Device Management

CLI, Secure Telnet and WEB Management Interfaces, Standard TR-069 Management, OTA Upgrade Support (http, ftp, and TR069), Dual Image Bank Support for Safe Upgrade, Device Factory Default Setting.
