Physical & Environmental

Power

DC 48V/0.32A, <15W

Weight

<1.5Kg

Dimensions

198mm(L) * 194mm(W) * 48mm(D)

Environment

Operating Temperature, -40℃~55℃. Humidity, 95% max Non-condensing

Water Resistance

IP67

LTE Radio Interface

Radio Access

3GPP LTE Release 9, Category 4

Operation Mode

1T2R, TxD, DL 2x2 MIMO, Optional UL QAM64 Support

Frequency Band

B3, B12/17/20, B7/38/40/41, B42/43

QoS Support

Non-GBR and GBR

Max Tx Power

B3 & B12/17/20 & B7/38/40/41: 23dBm

B42/43: 27dBm

Antenna Gain

B12/17/20: 6dBi

B3:10dBi

B7/38/40/41: 12dBi

B42/43: 15dBi

User Interface

Data Interface

1 RJ45 10/100M ETH Ports

LED Indicator

PWR, SYS, LAN, SIM, RF (5 Signal intensity LEDs)

SIM Card

Single USIM Card Slot (2FF)

Configurations & Management

LTE Networking

Multiple PDN interface support, IPv4 & IPv6 Networking Support, APN, Channel and Band Configuration, Network Selection and Cell Locking Provision, SIM Card Locking Feature.

Basic Data Networking

Router and L3 Bridge Operation Mode Support, Built-in DHCP Server for LAN Devices, VPN Pass-through support (PPTP, L2TP and IPSEC), Firewall & Access Control, DMZ and Virtual Server Support, IP and Port Filtering Support, NTP Service Support.

Advanced Networking Features

Built-in L2TP L2/L3 Tunneling client support, Built-in GRE L2/L3 Tunneling client support, Device Management Access Control, Application Firewall Support, LAN Device Access Control.

Device Management

CLI, Secure Telnet and WEB Management Interfaces, Standard TR-069 Management, OTA Upgrade Support (http, ftp, and TR069), Dual Image Bank Support for Safe Upgrade, Device Factory Default Setting.
