AirMaster 4000V/N


Available Models

AirMaster 4000N: Outdoor CPE

AirMaster 4000V: Outdoor VoIP CPE

Physical & Environmental

Power

DC 24V/0.75A, <20W (Passive PoE)

Weight

<1.5Kg

Dimensions

310mm(L) * 122mm(W) * 75mm(D)

Environment

Operating Temperature, -40~55. Humidity, 95% max Non-condensing

Water Resistance

IP 67

LTE Radio Interface

Radio Access

3GPP LTE Release 9, Category 4

Operation Mode

TDD, 2RX, 1TxD, DL MIMO

Frequency Band

B40, B41, B42/43

Max Tx Power

B40 & B41: 23dBm, B42/43: 27dBm

Antenna Gain

B40 & B41:10dBi, B42/43:12dBi

WiMAX Radio Interface

Radio Access

Mobile WiMAX 802.16e

Frequency Band

2.3~2.4GHz, 2.5~2.7GHz, 3.4~3.8GHz

Operation Mode

TDD, 2RX, 1TxD, DL MIMO

Channel Bandwidth

3/3.5/5/7/8.75/10MHz

Modulation

QPSK, QAM16, QAM64

FFT

1024/512 FFT Points

FEC

Convolution & Turbo Code

Authentication

TLS/TTLS

Max Tx Power

2.3~2.4GHz & 2.5~2.7GHz: 23dBm, 3.4~3.8GHz :27dBm

Antenna Gain

10dBi (2.3~2.4GHz & 2.5~2.7GHz), 12dBi (3.4~3.8GHz)

User Interface

Data Interface

1 RJ45 10/100M ETH Ports

1 RJ11 Line Port (AM4000V Only)

LED Indicator

SYS, SIM, ETH, RF (4 Signal intensity LEDs),

LINE (AM4000V Only)

SIM Card

Single USIM Card Slot (2FF)

Voice Features (AM4000V Only)

VoIP Processing

Compression G.711 G.721 G.723 G.726 G.729 G.722, Comfort Noise Comfort noise generation & control, Echo Cancellation G.165/168-2000, Silence Handling Silence detection/suppression, Fax Support T.30 and T.38, Delay/Jitter/Loss Jitter and packet loss compensation, DTMF Relay in band DTMF, RFC2833, SIP signal, Call Duration 24+ hours Uninterrupted Call.

Voice Services

[Basic Voices]: Local, domestic & international calling, Flexible dial plan configuration support, Tone customization for different countries.

[Supplement Services]: Caller ID, Caller ID suppression, Call Screening, Speed dial, Call Tracing, Hotline, Unconditional call forwarding, Call Forwarding No Answer, Call Forwarding on Busy, Call Waiting, Call Back, Call Blocking, No Disturbance, Alarm, Network and Local 3-way Call, Data Call, and etc.

Configurations & Management

Network Configuration

DHCP or static IP address assignment, Bridge and router operation support, Built-in DHCP server for LAN devices, IPv4, IPv6 DS-Lite support, Multiple PDN interface support, Cell and PLMN locking support.

Data Networking Features

VPN Pass-through support (PPTP, L2TP and IPsec), Built-in L2TP & GRE Tunneling client support, Firewall & Access Controlled and Virtual Server Support, IP and Port Filtering Support, Local and Remote Management Restriction, Application Firewall Support, LAN Device Access Control.

Device Management

CLI, Secure HTTP and HTTPS WEB Management Interfaces, Standard TR-069 Management, Device Factory Default Setting, FTP and HTTP OTA Firmware Upgrade.





Preview picture




Feature Highlights

  • Cost effective & compact design with built-in high gain LTE/WiMAX and Wi-Fi antenna
  • Compliant to 3GPP LTE R9 and 802.16e WiMAX Wave 2 specifications
  • Advanced MIMO support and Category 4 throughput
  • Dual LAN ports, SIP 2.0 VoIP and 802.11b/g/n MIMO Wi-Fi support
  • PPT, L2TP and GRE VPN Tunneling clients support
  • Router, bridge and by-pass networking, IPv4 &v6 and Multiple PDN support
  • FTP, HTTP and TR-069 management support
  • SIM card authentication and virtual SIM support
