AirMaster 3300D


Physical & Environmental

Power

DC 12V/1.0A, <10W, optional UPS battery backup

Weight

<380g

Dimensions

120mm(L) * 120mm(W) * 160mm(D)

Environment

Operating Temperature, -15~55. Humidity, 90% max Non-condensing

LTE Radio Interface

Radio Access

3GPP LTE Release 9, Category 4

Operation Mode

TDD+FDD 1T2R, DL 2x2 MIMO

Frequency Band

B3/7/20+B31, B3/7/20/40/41+B42/43

Max Tx Power

23 dBm

Antenna Gain

B3/7/20+B31: 2~4dBi, B3/7/20/40/41+B42/43: 3~6dBi

Wi-Fi Interface

Radio Access

IEEE 802.11 b/g/n (2x2 MIMO 300Mbps)

Tx Power

15dBm (2Tx)

Antenna

3dBi Built-in antenna

Max Users

32+

Security

64/128 bit WEP, WPA/WPA2

User Interface

Data Interface

1 RJ45 10/100M ETH Ports

LED Indicator

SYS, RF (4 Signal intensity LEDs), SIM, Wi-Fi, ETH

SIM Card

Single USIM Card Slot (2FF)

Configurations & Management

Network Configuration

DHCP or static IP address assignment, Bridge and router operation support, Built-in DHCP server for LAN devices, IPv4, IPv6 DS-Lite support, Multiple PDN interface support, Cell and PLMN locking support.

Data Networking Features

VPN Pass-through support (PPTP, L2TP and IPsec), Built-in L2TP & GRE Tunneling client support, Firewall & Access Controlled and Virtual Server Support, IP and Port Filtering Support, Local and Remote Management Restriction, Application Firewall Support, LAN Device Access Control.

Device Management

CLI, Secure Telnet and WEB Management Interfaces, Standard TR-069 Management, Device Factory Default Setting, Virtual SIM Card Support.





Preview picture




Feature Highlights

  • Cost effective & compact design with built-in high gain LTE and Wi-Fi antenna
  • Compliant to 3GPP LTE R9 specifications
  • Advanced 2x2 MIMO support and Category 4 throughput
  • Single FE LAN port and 802.11b/g/n MIMO Wi-Fi support
  • Router, bridge and by-pass networking, IPv4 &v6 and Multiple PDN support
  • VPN & full L2/L3 GRE Tunneling clients support
  • FTP, HTTP, HTTPS and TR-069 management support
  • SIM card authentication and virtual SIM support
  • UPS battery backup option
