AirMaster 3100D


Physical & Environmental

Power

DC 12V/1.0A, <10W, optional UPS battery backup

Weight

<350g

Dimensions

180mm(L) * 168mm(W) * 36mm(D)

Environment

Operating Temperature, -15~55. Humidity, 90% max Non-condensing

LTE Radio Interface

Radio Access

3GPP LTE Release 9, Category 5 capable

Operation Mode

TDD/FDD, 2RX, 1TxD, DL MIMO, UL QAM64

Frequency Band

B3/7/20, B31, B40/41, B42/43/48

Channel Bandwidth

1.4/3/5/10/15/20 MHz

QoS Support

Non-GBR and GBR

Max Tx Power

23dBm

Antenna Gain

B3/7/20: 3±1dBi, B31: 2±1dBi, B40/41:4±1dBi,

B42/43/48: 5±1dBi

Wi-Fi Interface

Radio Access

IEEE 802.11 b/g/n (2x2 MIMO 300MHz)

Tx Power

15dBm (2Tx)

Antenna

3dBi Built-in antenna

Connected Users

6

Security

64/128 bit WEP, WPA/WPA2

User Interface

Data Interface

1 RJ45 10/100M ETH Ports

LED Indicator

SYS, Wi-Fi, RF (3 Signal intensity LEDs)

SIM Card

Single USIM Card Slot (2FF)

Configurations & Management

Network Configuration

DHCP or static IP address assignment, Bridge and router operation support, Built-in DHCP server for LAN devices, IPv4, IPv6 DS-Lite support, Multiple PDN interface support, Cell and PLMN locking support. NTP Service Support.

Data Networking Features

VPN Pass-through support (PPTP, L2TP and IPsec), Built-in L2TP & GRE Tunneling client support, Firewall & Access Controlled and Virtual Server Support, IP and Port Filtering Support, Local and Remote Management Restriction, Application Firewall Support, LAN Device Access Control.

Device Management

CLI, Secure Telnet and WEB Management Interfaces, Standard TR-069 Management, Device Factory Default Setting, Virtual SIM Card Support.





Preview picture




Feature Highlights

  • Cost effective & compact design with built-in high gain LTE and Wi-Fi antenna
  • Compliant to 3GPP LTE R9 specifications
  • Advanced 2x2 MIMO support and Category 5 throughput
  • Single FE LAN port and 802.11b/g/n MIMO Wi-Fi support
  • VPN & full L2/L3 GRE Tunneling clients support
  • Router, bridge and by-pass networking, IPv4 &v6 and Multiple PDN support
  • FTP, HTTP, HTTPS and TR-069 management support
  • UPS battery backup option
